New Vios Specification

Transmisi / Transmission Type CVT CVT - - - 5 MT
Suspensi Depan / Front Suspension - - - - - MacPherson strut
Suspensi Belakang / Rear Suspension - - - - - Torsion Beam
Rem Depan / Front Brake 15” Ventilated Disc 15" Ventilated Disc - - - 15” Ventilated Disc
Rem Belakang / Rear Brake Solid Disc with EPB Solid Disc with EPB - - - Drum
Ukuran Ban / Tires Size 205/50 R17 205/50 R17 - - - 195/60 R16
Power Steering Electric Power Steering - - - -
Rem Tangan / Parking Brake Tuas Elektrik / Electrical Switch with Auto Brake Hold - - - -

Overall Panjang / Length (mm) 4.410 4.410 - - - 4.410
Overall Lebar / Width (mm) 1.740 1.740 - - - 1.740
Overall Tinggi / Height (mm) 1.480 1.480 - - - 1.480
Jarak Poros Roda / Wheelbase (mm) 2.620 2.620 - - - 2.620
Jarak Pijak Depan / Front Tread (mm) 1.510 - - - - 1.520
Jarak Pijak Belakang / Rear Tread (mm) - - - - - 1.500
Jarak Terendah / High Ground Clearanace (mm) 160 - - - - 160
Overhang Depan (mm) 860 - - - - 860
Overhang Belakang (mm) 945 - - - - 945

Tipe Mesin / Engine Type 4 Cylinders, In-line 16-Valves DOHC with Dual VVT-i 4 Cylinders, In-line 16-Valves DOHC with Dual VVT-i - - - 4 Cylinders, In-line 16-Valves DOHC with Dual VVT-i
Isi Silinder / Displacement (cc) 1,496 1,496 - - - 1.496
Daya Maksimum / Maximum Output (ps/rpm) 78 / 6.000 78 / 6.000 - - - 78 / 6.000
Torsi Maksimum / Maximum Torque (kgm/rpm) 138 / 4.200 138 / 4.200 - - - 138 / 4.200
Emission Certification - - - - - EURO 4
Bahan Bakar / Fuel - - - - - Gasoline
Kapasitas Tangki / Fuel Capacity (Liter) - - - - - 40
Bore x Stroke (mm) 72,5 x 90,6 72.5 x 90.6 - - - 72,5 x 90,6
Sistem Bahan Bakar / Fuel System Sistem Injeksi Elektronik / Electronic Fuel Injection (EFI) Gasoline - - - Sistem Injeksi Elektronik / Electronic Fuel Injection (EFI
